NBN. At Last!

And about the last.  The fibre optic network was commenced about 3 years ago, and I applied for a connection shortly after.

Despite living in the centre of Victoria’s second biggest city, my house was not connected to the National Broadband Network until today.

Until then I have coped with download speeds as low as 1mb/sec, and uploads as slow as 60kb/sec.  Do you wonder why I upload so few videos?

Today, the NBN was finally connected.  The download speed is a blistering 50mb/sec, and uploads 25mb/sec.  Wow!

Just to celebrate, I am posting some pictures.  Not much to report from the workshop, but I am accumulating some items in readiness for rifling the model cannon bore.

P1053654

This photograph would typically have taken 60-120 seconds to upload previously.  Today it took about 5 seconds!    As you can see it is a cold saw blade which has seen better days.  My bad, unfortunately.   But I saved the pieces,  because these blades are made of high quality tool steel.  I have had some parts laser cut .

P1053653

The laser cutter left the tabs intact so the tiny parts would not be lost.

P1053655

The 2.5mm thick part popped out with a bit of finger pressure.  Not much tidying up required here, but I will sharpen the cutting edge.  This will be the cutter for the rifling of the model cannon.

This is the first time I have had parts laser cut, and I am impressed by the accuracy and smoothness of the cut and the narrow kerf (0.2mm).    Oh, and the cost.  It was surprisingly inexpensive.  ($AUD26).



30 watt Laser in action.

Not mine, unfortunately.  This one is Stuart Tankard’s.  It is a Ytterbium generated, 30w, fibre laser, and the wavelength is such that the 0.01mm diameter beam will burn holes in metal.  Ytterbium, for those who can’t be bothered to look it up,  is a rare earth metal, atomic number 70,  Stuart has used the laser to cut parts from a 1.2mm thick hacksaw blade.  And in the following video he is making marks in a work-tool rest which I will use on my Radius Master sander grinder.



It is a 360º protractor, and grid lines at 10mm intervals.   Looks purposeful.  Time will tell if it is useful.

Watch the video.  I am experiencing tool envy.



Listening to my own voice is pretty painful.  I hope that it doesn’t grate too much on you.
